Rod Resistors are available in a wide assortment of diameters and lengths to meet your application needs. Standard rod resistor applications include high power loads, snubber circuit RF power amplifiers, impulse voltage generators, high voltage circuits and power supplies, X-ray equipment, and dummy loads. The ceramic composition rods perform well where high peak power or high energy pulses are required to be handled. These non-inductive resistors are able to dissipate the energy uniformly through the entire resistor body. The rods are available with a number of terminations available to meet your connecting requirements, including straight brass terminals or rounded edges. Various Metal Terminals are available for utilization in the installation and electrical connections. Please see under the Products Tab / Available Terminals.
| Part Number | Diameter (Inches) | Length* (Inches) | Low (Ohms) | High (Ohms) | Power (Watts) | Energy (Joules) | Voltage (Maximum) |
|---|---|---|---|---|---|---|---|
| 83-RC02 Resistor Rods |
0.500 | 2 | 9.0 | 40,000 | 4.7 | 1,800 | 10,000 |
| 83-RC04 Resistor Rods |
0.500 | 4 | 17.0 |
81,000 |
9.4 | 3,700 | 20,000 |
| 83-RC06 Resistor Rods |
0.500 | 6 | 25.0 |
122,000 |
14.1 | 5,600 | 40,000 |
| 83-RC08 Resistor Rods |
0.500 | 8 | 33.0 |
162,000 |
18.8 | 7,500 | 60,000 |
| 83-RC10 Resistor Rods |
0.500 | 10 | 41.0 |
203,000 |
23.6 | 9,400 | 80,000 |
| 83-RC12 Resistor Rods |
0.500 | 12 | 49.0 |
244,000 |
28.3 | 11,300 | 100,000 |
| Part Number | Diameter (Inches) | Length* (Inches) | Low (Ohms) | High (Ohms) | Power (Watts) | Energy (Joules) | Voltage (Maximum) |
|---|---|---|---|---|---|---|---|
| 83-RD02 Resistor Rods |
0.750 | 2 | 4.0 | 18,000 | 10.6 | 4,200 | 10,000 |
| 83-RD04 Resistor Rods |
0.750 | 4 | 8.0 | 36,000 | 21.2 | 8,400 | 20,000 |
| 83-RD06 Resistor Rods |
0.750 | 6 | 11.0 | 54,000 | 31.8 | 12,700 | 40,000 |
| 83-RD08 Resistor Rods |
0.750 | 8 | 15.0 | 72,000 | 42.4 | 16,900 | 60,000 |
| 83-RD10 Resistor Rods |
0.750 | 10 | 19.0 | 90,000 | 53.0 | 21,200 | 80,000 |
| 83-RD12 Resistor Rods |
0.750 | 12 | 22.0 | 108,000 | 63.6 | 25,400 | 100,000 |
| Part Number | Diameter (Inches) | Length* (Inches) | Low (Ohms) | High (Ohms) | Power (Watts) | Energy (Joules) | Voltage (Maximum) |
|---|---|---|---|---|---|---|---|
| 83-RE02 Resistor Rods |
1.000 | 2 | 3.0 | 10,000 | 18.0 | 7,500 | 10,000 |
| 83-RE04 Resistor Rods |
1.000 | 4 | 4.0 | 20,000 | 37.0 | 15,000 | 20,000 |
| 83-RE06 Resistor Rods |
1.000 | 6 | 7.0 | 30,000 | 56.0 | 22,600 | 40,000 |
| 83-RE08 Resistor Rods |
1.000 | 8 | 9.0 | 40,000 | 75.0 | 30,100 | 60,000 |
| 83-RE10 Resistor Rods |
1.000 | 10 | 11.0 | 50,000 | 94.0 | 37,600 | 80,000 |
| 83-RE12 Resistor Rods |
1.000 | 12 | 13.0 | 61,000 | 113.0 | 45,200 | 100,000 |
| 83-RE14 Resistor Rods |
1.000 | 14 | 15.0 | 71,000 | 131.0 | 52,700 | 120,000 |
| 83-RE16 Resistor Rods |
1.000 | 16 | 17.0 | 81,000 | 150.0 | 60,300 | 140,000 |
| 83-RE18 Resistor Rods |
1.000 | 18 | 18.0 | 91,000 | 169.0 | 67,800 | 160,000 |
| Part Number | Diameter (Inches) | Length* (Inches) | Low (Ohms) | High (Ohms) | Power (Watts) | Energy (Joules) | Voltage (Maximum) |
|---|---|---|---|---|---|---|---|
| 83-RF02 Resistor Rods |
1.500 | 2 | 1.0 | 4,500 | 40.0 | 16,000 | 10,000 |
| 83-RF04 Resistor Rods |
1.500 | 4 | 2.0 | 9,000 | 80.0 | 33,000 | 20,000 |
| 83-RF06 Resistor Rods |
1.500 | 6 | 3.0 | 13,500 | 125.0 | 50,000 | 40,000 |
| 83-RF08 Resistor Rods |
1.500 | 8 | 4.0 | 18,000 | 165.0 | 67,000 | 60,000 |
| 83-RF10 Resistor Rods |
1.500 | 10 | 5.0 | 22,000 | 210.0 | 84,000 | 80,000 |
| 83-RF12 Resistor Rods |
1.500 | 12 | 6.0 | 27,000 | 250.0 | 101,000 | 100,000 |
| 83-RF14 Resistor Rods |
1.500 | 14 | 7.0 | 31,000 | 290.0 | 118,000 | 120,000 |
| 83-RF16 Resistor Rods |
1.500 | 16 | 8.0 | 36,000 | 335.0 | 135,000 | 140,000 |
| 83-RF18 Resistor Rods |
1.500 | 18 | 9.0 | 40,000 | 380.0 | 152,000 | 160,000 |
| Part Number | Diameter (Inches) | Length* (Inches) | Low (Ohms) | High (Ohms) | Power (Watts) | Energy (Joules) | Voltage (Maximum) |
|---|---|---|---|---|---|---|---|
| 83-RG02 Resistor Rods |
1.625 | 2 | 0.9 | 3,800 | 44.0 | 19,000 | 10,000 |
| 83-RG04 Resistor Rods |
1.625 | 4 | 1.7 | 7,700 | 95.0 | 39,000 | 20,000 |
| 83-RG06 Resistor Rods |
1.625 | 6 | 2.5 | 11,500 | 145.0 | 59,000 | 40,000 |
| 83-RG08 Resistor Rods |
1.625 | 8 | 3.3 | 15,400 | 195.0 | 79,000 | 60,000 |
| 83-RG10 Resistor Rods |
1.625 | 10 | 4.0 | 19,200 | 245.0 | 99,000 | 80,000 |
| 83-RG12 Resistor Rods |
1.625 | 12 | 4.8 | 23,100 | 295.0 | 119,000 | 100,000 |
| 83-RG14 Resistor Rods |
1.625 | 14 | 5.6 | 27,000 | 345.0 | 139,000 | 120,000 |
| 83-RG16 Resistor Rods |
1.625 | 16 | 6.3 | 30,800 | 395.0 | 159,000 | 140,000 |
| 83-RG18 Resistor Rods |
1.625 | 18 | 6.9 | 34,700 | 445.0 | 179,000 | 160,000 |
| Part Number | Diameter (Inches) | Length* (Inches) | Low (Ohms) | High (Ohms) | Power (Watts) | Energy (Joules) | Voltage (Maximum) |
|---|---|---|---|---|---|---|---|
|
85-RC02
|
0.525
|
2
|
18
|
36,000
|
4.7
|
1,800
|
10,000
|
|
85-RC04
|
0.525
|
4
|
36
|
72,000
|
9.4
|
3,700
|
30,000
|
|
85-RC06
|
0.525
|
6
|
56
|
110,000
|
14.1
|
5,600
|
50,000
|
|
85-RC08
|
0.525
|
8
|
74
|
145,000
|
18.8
|
7,500
|
70,000
|
|
85-RC10
|
0.525
|
10
|
92
|
184,000
|
23.6
|
9,400
|
90,000
|
|
85-RC12
|
0.525
|
12
|
110
|
220,000
|
28.3
|
11,300
|
110,000
|
| Part Number | Diameter (Inches) | Length* (Inches) | Low (Ohms) | High (Ohms) | Power (Watts) | Energy (Joules) | Voltage (Maximum) |
|---|---|---|---|---|---|---|---|
|
85-RD02
|
0.775
|
2
|
8
|
16,000
|
10.6
|
4,200
|
10,000
|
|
85-RD04
|
0.775
|
4
|
18
|
32,000
|
21.2
|
8,400
|
30,000
|
|
85-RD06
|
0.775
|
6
|
26
|
50,000
|
31.8
|
12,700
|
50,000
|
|
85-RD08
|
0.775
|
8
|
34
|
67,000
|
42.4
|
16,900
|
70,000
|
|
85-RD10
|
0.775
|
10
|
44
|
84,000
|
53.0
|
21,200
|
90,000
|
|
85-RD12
|
0.775
|
12
|
52
|
100,000
|
63.6
|
25,400
|
110,000
|
| Part Number | Diameter (Inches) | Length* (Inches) | Low (Ohms) | High (Ohms) | Power (Watts) | Energy (Joules) | Voltage (Maximum) |
|---|---|---|---|---|---|---|---|
|
85-RE02
|
1
|
2
|
6
|
10,000
|
18.8
|
7,500
|
10,000
|
|
85-RE04
|
1
|
4
|
10
|
20,000
|
37.7
|
15,000
|
30,000
|
|
85-RE06
|
1
|
6
|
16
|
30,000
|
56.5
|
22,600
|
50,000
|
|
85-RE08
|
1
|
8
|
22
|
40,000
|
75.4
|
30,100
|
70,000
|
|
85-RE10
|
1
|
10
|
26
|
50,000
|
94.2
|
37,600
|
90,000
|
|
85-RE12
|
1
|
12
|
32
|
60,000
|
113.1
|
45,200
|
110,000
|
|
85-RE14
|
1
|
14
|
36
|
70,000
|
131.9
|
52,700
|
130,000
|
|
85-RE16
|
1
|
16
|
42
|
80,000
|
150.8
|
60,300
|
150,000
|
|
85-RE18
|
1
|
18
|
46
|
90,000
|
169.6
|
67,800
|
170,000
|
| Part Number | Diameter (Inches) | Length* (Inches) | Low (Ohms) | High (Ohms) | Power (Watts) | Energy (Joules) | Voltage (Maximum) |
|---|---|---|---|---|---|---|---|
|
85-RF02
|
1.5
|
2
|
2.5
|
4,500
|
42.4
|
16,900
|
10,000
|
|
85-RF04
|
1.5
|
4
|
4.8
|
9,000
|
84.8
|
33,900
|
30,000
|
|
85-RF06
|
1.5
|
6
|
7.0
|
13,000
|
127.2
|
50,800
|
50,000
|
|
85-RF08
|
1.5
|
8
|
9.5
|
18,000
|
169.6
|
67,800
|
70,000
|
|
85-RF10
|
1.5
|
10
|
11.5
|
22,000
|
212.1
|
84,800
|
90,000
|
|
85-RF12
|
1.5
|
12
|
14.0
|
27,000
|
254.5
|
101,700
|
110,000
|
|
85-RF14
|
1.5
|
14
|
16.0
|
31,000
|
296.9
|
118,700
|
130,000
|
|
85-RF16
|
1.5
|
16
|
18.5
|
36,000
|
339.3
|
135,700
|
150,000
|
|
85-RF18
|
1.5
|
18
|
20.5
|
40,000
|
381.7
|
152,600
|
170,000
|
| Part Number | Diameter (Inches) | Length* (Inches) | Low (Ohms) | High (Ohms) | Power (Watts) | Energy (Joules) | Voltage (Maximum) |
|---|---|---|---|---|---|---|---|
|
85-RG02
|
1.64
|
2
|
2.0
|
3,700
|
49.8
|
19,900
|
10,000
|
|
85-RG04
|
1.64
|
4
|
4.0
|
7,500
|
99.5
|
39,800
|
30,000
|
|
85-RG06
|
1.64
|
6
|
5.8
|
11,000
|
149.3
|
59,700
|
50,000
|
|
85-RG08
|
1.64
|
8
|
7.8
|
15,000
|
199.1
|
79,600
|
70,000
|
|
85-RG10
|
1.64
|
10
|
9.5
|
18,500
|
248.9
|
99,500
|
90,000
|
|
85-RG12
|
1.64
|
12
|
11.5
|
22,500
|
298.6
|
119,400
|
110,000
|
|
85-RG14
|
1.64
|
14
|
13.5
|
26,000
|
348.4
|
139,300
|
130,000
|
|
85-RG16
|
1.64
|
16
|
15.5
|
30,000
|
398.2
|
159,200
|
150,000
|
|
85-RG18
|
1.64
|
18
|
17.5
|
33,500
|
448.0
|
179,100
|
170,000
|
Part Number plus the Resistance Code is used for specifying a particular part. The Resistance code is defined by the first two numbers of the resistance value, followed by a single number multiplier, and the resistance tolerance (20% is L, 10% is K, 5% is J). When the resistance is less than 10 ohms, the multiplier is not used and replaced by an “R”.
For example a 0.775” x 6.0” Resistor Rod at 5.0 ohms +/-10% would be qualified as “85-RD06-5R0K, and a 1.50” x 16.0 Resistor Rod at 150 ohms +/-20% is 85-RF16-151L.
For more information about Rod Resistors, please CONTACT US.
